Test stand capable of measuring and logging rocket motor thrust up to 200kg with frequency of 2000Hz. Custom mechanical, electronic and software design.

ESP32 based flight controller for a homemade rocket. It features a high g accelerometer, barometer, SD card for logging, buzzer, neopixel LED, control button, 1S li-ion charger, USB/battery automatic power switching, battery voltage reading, switchable power rail for peripherals and 2 high current outputs with support for remove before flight pins for ejection charges.

DIY 6s7p 420Wh li-ion battery from used 18650 cells soldered together. Used to charge LiPo packs for my FPV drones.
